- Specification
- System
External I/O Port
– 1 x OSD buttons (LED / Power / Enter/ Menu/Up/Down)
– 1 x VGA
– 1 x HDMI
– 1 x AUDIO Jack
– 1 x DC power adapter
- Touch Screen
Type
P-cap USB touch, 7H Hardness
- LCD
Display Type
10.1″ TFT LCD
Max. Resolution
1280*800 (Optional to 1920 x 1200)
Max. Color
16.7M
Luminance (cd/m2)
350 nits (Optional 1000 nits)
View Angle
85 / 85 / 85 / 85
Backlight Lifetime
30,000 hours
- Power Requirement
Power Input
DC 12V
- Environment
Operating Temp
0~45 °C,IEC-60068-2-1/2/14
Storage Temp.
-20~60 °C
Humidity
10~90% @40 °C, non-condensing
- Mechanical
Construction
Metal
IP Rating
N/A
Mounting
Open Frame Bezel Mounting
Dimension
As below drawing
- Ordering Information
- Ordering Information
TOF-P101W
10.1” P-cap touch open frame monitor
TOF-P101WF
10.1” P-cap touch open frame monitor with Anti-Reflection
TOF-P101W2H
10.1” P-cap touch open frame monitor with 1920 x 1200 and 1000 nits
TOF-P101W2HF
10.1” P-cap touch open frame monitor with 1920 x 1200 and 1000 nits, and Anti-Reflection.
