X-CORLEONE Series: PQC-Ready Edge Security for Defense-Grade Protection

X-Corleone

X-Corleone Series

From Cloud to Combat, a Secured AI Server in Edge.

Product Highlights - Advantages and Benefits

Post-Quantum Cryptography (PQC) for Quantum Safe. (NIST FIPS 203/204)
X-Corleone Safe Platform for device management
Dual TPM 2.0 for secure boot
Strong authentication
TLS 1.3 with PQC secure communication
Full Disk encryption technologies
Intel® Core i3-13300HRE / i5-13600HRE / i7-13800HRE
Quadro® RTX A2000 — CUDA 2560 AI Engine / GDDR6 8G
Operating Temperature -40°C to 70°C
IP67 & Fanless Design
DC 9-36V Power Input
MIL-STD-810H/461G/1275E Certificated

Feature

Military-Grade Reliability — Compliant with MIL-STD-810H/461G, wide-temp operation (-40°C to 70°C), fanless design
Dual TPM Key Authentication Encryption
Ruggedized & Sealed Design — IP67, salt-fog resistance, corrosion protection
Customizable I/O & Military Connectors (MIL-DTL-38999)
NIST approved PQC (Post-Quantum Cryptography) standards including FIPS 203 & 204
Quantum Safe TLS (Transport Layer Security) Communication

Advantage

Ensures stable operation in harsh environments with reduced failure risk
Provides hardware-level dual-key architecture for secure boot, device authentication, and full disk encryption
Withstands dust, water, and corrosive environments
Flexible system integration for diverse missions
Leading security solution for defense computing
Provides end-to-end encryption, ensuring data integrity and confidentiality during transmission

Benefit

Customers can deploy systems confidently in mission-critical and outdoor applications with minimal downtime and lower total cost of ownership (TCO)
Customers gain an additional security layer, making unauthorized system access nearly impossible and meeting high-level defense and government security standards
Extends product life cycle and reduces maintenance frequency, providing long-term protection
Customers can adapt the system to specific military operational needs, saving development time and accelerating deployment
Safe grounding communication to prevent Harvest-now-decrypt-later (HNDL) attacks
Customers can securely transmit AI models, control signals, and mission data without fear of interception, reducing risks of Man-in-the-Middle (MITM) attacks and building trust in networked deployments

System
CPU	13th Gen Intel® Core i3-13300HRE / i5-13600HRE / i7-13800HRE
System Memory	1x Dual-Channel SO-DIMM Slot for ECC DDR5, 5200 MT/s, Default 32GB, up to 96GB
AI Computing	1x MXM 3.1 Type A Slot for GPU Card, Quadro® RTX A2000, GDDR6 8G
External I/O Port	2x USB 3.2 Gen2 2x 10 GbE 1x 2.5 GbE (Optional) 1x 1.0 GbE (Optional) 4x 2.5 GbE PoE+, Total 100W Power Budget 1x HDMI 2.1 2x Serial Port (RS-232/422/485 selectable) (Optional) 1x DC Power Input 1x Power Button All IOs by D38999 Connector
Storage	1x M.2 Slot (M Key, 2280) for NVMe M.2 SSD, default 1TB, up to 2TB 1x SATA III and SATA Power Slot for 2.5" SSD (Internal Slot)
Operation System	Windows 11 (TBC) Linux Ubuntu (Optional)
Expansion	1x M.2 Slot (E Key, CNVi, 2230) for Wireless Wi-Fi/BT module 1x M.2 Slot (B Key, 2242/3042) for WWAN 4G/5G module 1x SIM Slot
TPM	2 x TPM 2.0
Sub-system	NXP Layerscape LS1026A/LS1046A 3x USB 3.2 Gen 1 (Including USB 2.0) (Internal Connector) 1x M.2 Slot (M+B Key, 2280) for M.2 SATA III SSD (Internal Connector)

Environment
Power Input	DC 9-36V, 450W Power Input with MIL-STD-461G/1275E Certification
Dimension	TBC
Certification	EMC • MIL-STD-461G Certification (CE101/CE102/RE101/RE102) • FCC / CE Class A Certification Vibration • MIL-STD-810H, Method 514.8 Shock • MIL-STD-810H, Method 516.8
Operating Temp	-40~70°C
Storage Temp	-40~85°C
Humidity	10~90% @40 °C, non-condensing

Ordering Information
X-Corleone XC-133	Secured AI Server, 13th Gen Intel® Core i3-13300HRE, 32GB DDR5 5200MT/s, 1TB M.2 NVMe SSD, Quadro® RTX A2000 MXM GPU
X-Corleone XC-135	Secured AI Server, 13th Gen Intel® Core i5-13600HRE, 32GB DDR5 5200MT/s, 1TB M.2 NVMe SSD, Quadro® RTX A2000 MXM GPU
X-Corleone XC-137	Secured AI Server, 13th Gen Intel® Core i7-13800HRE, 32GB DDR5 5200MT/s, 1TB M.2 NVMe SSD, Quadro® RTX A2000 MXM GPU
