- Intel® TigerLake-UP3 Core™ i3/i5/i7 Processors
- 15.6" P-cap Flat Bezel
- 1920 x 1080 FHD Resolution
- 1000nits Backlight
- IP65 / 66 Front Panel
- Bezel-Free Design
- Fanless Design
- DC 9~36V Wide Range Power Input
- Ignition control with Delay On/Off
- 3-Pin Power Input Terminal Block
- Specification
- System
Intel® TigerLake-UP3 Core™ i3/i5/i7 Processors
System Memory
2 x DDR4 SO-DIMM, up to 64GB
External I/O Port
‧ 1 x HDMI
‧ 4 x RS-232/422/485
‧ 1 x Audio out
‧ 1 x Power press button
‧ 1 x 3-Pin Terminal Block for Power Input
Storage
‧ 1 x 2.5″ Storage Tray
‧ 1 x M.2 B-key 2242/3042 (SATA Signal)
‧ 1 x M.2 M-key 2280 (PCIe Gen.,4 x4 Signal)
Operating System
‧ Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2)
‧ Windows 11 IoT Enterprise (64-bit, 21H2, Pre-scan)
‧ Linux Ubuntu 22.04 (64-bit, by request)
‧ Linux Yocto Project 3.1 (64-bit, by request)
Expansion
‧ 1 x M.2 B-key 2242/3042 (PCIe x1, USB 2.0)
‧ 1 x M.2 E-key 2230 (PCIe x1, USB 2.0)
- LCD
Display Type
15.6″ TFT LCD
Max. Resolution
1920 x 1080
Contrast Ratio
800 : 1
Max. Color
16.2M
Luminance
1000nits
View Angle
85 / 85 / 85 / 85
- Touch Screen
Type
15.6″ P-cap USB interface
- Power Requirement
DC 9~36V Wide Range Power Input with Ignition control
- Environment
Operating Temp.
Storage Temp.
Humidity
10~90% @40 °C, non-condensing
Cerfitication
FCC/CE ClassA, FCC/CE ClassA
EMC
FCC / CE Class A Certification
Vibration & Shock
‧ MIL-STD-810H, Method 514.8, Procedure I, 5~500Hz (Compliance)
‧ MIL-STD-810H, Method 516.8, Procedure I, 20g 11ms (Compliance)
Mounting
VESA Mount 75 x 75 / 100 x 100 by M4 Screw Hole
- Ordering Information
- Ordering Information
LPC-P156WHAG-2T3V
15.6″ (1920 x 1080) Vehicle P-cap Panel PC, Intel® TigerLake-UP3 Core™ i3-1115G4E, 1000nits, IP65 Front Bezel, AG, 2.5″ Storage Tray, Ignition control with Delay On/Off, DC 9~36V Power Input, -40~70°C
LPC-P156WHAG-2T5V
15.6″ (1920 x 1080) Vehicle P-cap Panel PC, Intel® TigerLake-UP3 Core™ i5-1145G7E, 1000nits, IP65 Front Bezel, AG, 2.5″ Storage Tray, Ignition control with Delay On/Off, DC 9~36V Power Input, -40~70°C
LPC-P156WHAG-2T7V
15.6″ (1920 x 1080) Vehicle P-cap Panel PC, Intel® TigerLake-UP3 Core™ i7-1185G7E, 1000nits, IP65 Front Bezel, AG, 2.5″ Storage Tray, Ignition control with Delay On/Off, DC 9~36V Power Input, -40~70°C
- Ordering Code
LPC-P156WHAG-2TxV
-H / -OB / -B / -AG / -AR / -V
H = High Brightness 1000 nits LED backlight
OB = Optical Bonding
B = Glass withtout touch
AG = Anti-Glare
AR = Anti-Reflection
V = Vandal Proof Glass (By Project)
