By dropping a steel ball above the screen, we have verified our P-cap touch screen with a 6 mm coverglass.  The testing result is passed and amazing.

Elgens provides 25.3” Bar-Type LCD with 4K resolution, P-cap touch, EMI mesh, optical bonding, 1000 nits, Anti-Glare future for defense applications.

21.5” Brightness Controll by Knob and Touch Sensor
Picture-In-Picture (PIP) Testing

15.6” Darkness Test to 1.7 nits

15” Touch Glass Vandalproof Test
12 1” Resistive Multi-Touch Test
Mosmitle Film for Anti-Reflection
21.5” Night Vision Image System (NVIS)
video-16 levels

Elgens announces the high brightness backlight control by the knob for Panel PC with 16 levels.

waterproof test

01. Simulation of small raining situation
The P-cap Touch Function is passed by 90 degree normal installation outdoor. No influenced.

waterproof test

02. Simulation of the huge rain with some water when Panel PC lays on 180 degrees. The touch function works in major area, but once the water area enlarges, it influences the touch function at water area, the other area function is still no influenced.

waterproof test

03. Simulation the heavy rain with big area water when Panel PC lays on 180 degrees. The touch function is NG for the water area, even no touch on display but water area show incorrect Touch signal.
Normally the Touch Panel should be standing Vertical by 90 degrees.( our testing is the most strict one for flat 180 degrees )Over all, the touch function are passed after wipe the water.

Timezero Navigator Version 4 Compatibility Test

Timezero Navigator Version 4 works successfully on LPC-P156W-26, which is an IEC-60945 certificated 15.6″ Panel PC with intel i5-6300U by operating temp -30~70 °C. Below is the testing video for your reference.

LPC-P121 operateson 60degrees

12.1″ P-cap Panel PC (LPC-P121S-01) operates on 60 degrees with additional backside heatsink

LPC-P121 operateson 20degrees

12.1″ P-cap Panel PC (LPC-P121S-01) operates on -20 degrees

wide temperature test

18.5″ Resistive  Panel PC (LPC-185W) operates on -30 degrees.

wide temperature test

12.1″ Resistive  Panel PC (LPC-121S-01) operates on -30 degrees.

70 Degrees Operating Temp Test

LPC-P150S-26, 6th Core i5-6300U, operating on 70℃ for 24 hours / 4 cycles.

-20C cold start

LPC-215W cold boot testing on -20 ℃

-30C cold start

LPC-P150S-26, 6th Core i5-6300U, cold start 2nd times on -30 degrees

LPC P156 temp test A

LPC-P156W-2VE2 is a 15.6″ P-cap Full HD Panel PC with i3-6100U, IPS wide viewing angle, and 1600 nits backlight.

-40C cold start

LPC-P156W-2VE2 cold start testing (1st time 2 hours)

-40C cold start

LPC-P156W-2VE2 cold start testing (2nd time 4 hours)

LPC-P156 Power On -40C test report
LPC-P156 Power On -40C test report
-50℃ Temp Test

LPC-P156W-2VE2, which includes 1000nit backlight, has passed -50℃ for 2 hours with burning test 100% computing power. The test includes 2 cycles, and each cycle is about 2 hours.

ELGENS launches its latest LPC-P156W-10, 15.6″ Bezel-Free Panel PC passed by vibration test 1.5 Grms, following IEC-60068-2-64 standard.

Vibration Test

LPC-P156W-10 operates with Full HD 1920*1080 resolution, supporting

EtherCat IO Slave Kits

EMB-6100S works w/ TwinCat & EtherCat Slave IO kits

wago

ELGENS EMB-6100S working with WAGO 750-354 EtherCAT Fieldbus Coupler through Codesys

Siemens

LPC-P150S works with OPC server and Siemens PLC S7-1200

Siemens

LPC-P121S-01 works with Kepware OPC server and Siemens PLC S7-1200

Rockwell Automation

LPC-P150S works with OPC server and Rockwell PLC Micrologix 1400

Rubber Glove Touch Test

LGENS launches its latest 12″, 17″, 18.5″ Bezel-Free Panel PC.
LPC-P121S-10,
LPC-P170S-10,
LPC-P185W-10,
support rubber glove touch, passed by vibration test 1.5 Grms, smoothly without any interference, supporting wide temp from -20 to 60 degrees.
